CORE BUSSINESS

QFN TAPE

QFP TAPE

UV TAPE

ESD UV TAPE

BG TAPE


QFN lead frame protection tape  is a tape specially used for chip packaging processes. It is mainly used to stick to the back of the chip lead frame to prevent Molding resin from penetrating into the shielding area during the Molding process. This tape has good temperature resistance and anti-static properties, and can be used in high temperature environments and has no residual glue after removal.



QFP pin fixing tape is used in various IC packaging, and the hot pressing process arranges components on the lead frame in an orderly manner. 3KZ-QFP66, mainly designed for IC packages, pin xation.



BG Tape is a key protective material in semiconductor wafer thinning process. Through high-precision bonding and controllable peeling technology, the integrity and yield of the chip in processing is ensured.



ESD UV tape achieves a balance between wafer protection, electrostatic protection and process compatibility in semiconductor manufacturing through anti-static, rapid curing, easy peeling and other characteristics. It is a key auxiliary material for advanced processes (such as 3D integration, heterogeneous packaging).



After UV tape is cured by ultraviolet irradiation, the wafer and support glass can be quickly bonded to form a temporary fixed structure. This bonding method can keep the wafer stable during processing, avoid movement or damage, and protect the wafer surface from contaminants.



CERTIFICATION

ISO14001认证

ISO9001认证

QC080000认证

MAO SEN COMPANY PROFILE



              Guangdong Maosen Chip Materials Co., Ltd., a subsidiary of 3T Technology International Group, was established in 2011 with a registered capital of 139 million yuan. The company owns a 50,000-square-meter self-built modern factory integrating R&D, production, and administrative centers, equipped with standard 10,000-class cleanroom workshops, 9 precision coating lines with 100-class cleanrooms, and ultra-precision slitting equipment. Our professional R&D team has long been dedicated to the development and production of application solutions for auxiliary materials such as Chip factory, Wafer, Semiconductor, and New energy. The company has obtained three major certifications: ISO9001, ISO14001, and QC080000.  Main products include QFN packaging tape, QFP tape, UV dicing film, wafer thinning BG tape, and other semiconductor process application materials, which can perfectly compete with American, Japanese, and Korean brands. We aim to help semiconductor-related customers achieve cost reduction, efficiency improvement, and domestic substitution while creating value, improving chip yield, reducing power consumption, supporting sub-5nm processes, and addressing random defects encountered during packaging. We specialize in the R&D and production of semiconductor process materials.








1
More
  • 1.6nm, wafer level super packaging, silicon photonic integration... TSMC North America

    1.6nm, wafer level super packaging, silicon photonic integration... TSMC North America

    According to a report from Jiweiwang, TSMC held the 2024 North American Technology Forum in California, USA at the end of April, announcing six major semiconductor technology innovations including its latest semiconductor process technology A16 (1.6nm), next-generation advanced packaging, and 3D chip technology, which attracted industry attention. Under the global trend of developing artificial intelligence (AI), TSMC has become the most important foundry for AI chips such as Nvidia, thanks to its leading chip technology and stable expansion of production capacity.

  • The Development History of Semiconductor Technology

    The Development History of Semiconductor Technology

    Semiconductor technology is an indispensable technology in today's world, which affects various aspects of our lives. Its importance stems from its ability to manufacture small and precise electronic devices that can control current and information flow at the electronic level. This control capability enables us to create processors with extremely fast computing speeds, chips that store large amounts of data, devices that enable high-speed communication, and even scientific tools for exploring unknown fields.

  • Huagong Technology: We have completed the development of laser wafer precision cutting equipment pro

    Huagong Technology: We have completed the development of laser wafer precision cutting equipment pro

    On April 28th, in the financial industry, an investor asked Huagong Technology on an interactive platform: Jiufengshan Laboratory, in collaboration with Huagong Technology, is promoting collaborative innovation and achieving the latest achievement in the localization of high-end equipment - the national production of semiconductor wafer laser cutting machines has completed pilot testing and is expected to become a new growth point for enterprises in the future. May I ask if the semiconductor equipment company is involved in the design and manufacturing? Does the company have plans to enter advanced semiconductor manufacturing equipment?

  • Huawei plans to cooperate with SMIC to develop 3-nanometer process chips

    Huawei plans to cooperate with SMIC to develop 3-nanometer process chips

    US technology website revealed that Huawei and Chinese chip manufacturer SMIC plan to collaborate in the development of 3-nanometer process chips.
